Product Overview
The 400.110 Catch Basin is engineered for superior performance in demanding underground utility
applications.
Design Features
- Robust Construction: Made from Grade 25 cast iron for maximum strength and
impact resistance
- Corrosion Resistance: Special coating and material composition prevent rust
and degradation
- Easy Access: Designed for convenient maintenance and inspection access
- Safety Compliant: Meets all industry safety standards and regulations
- Weatherproof: Performs reliably in all weather conditions and temperatures
Technical Specifications
| Item |
Catch Basin OPSD 400.110 |
| Product Description |
400.110 |
| Material |
Cast Iron |
| Coating |
Asphalt |
| Standard |
ASTM A48 Class 30B |
Installation Guidelines
Preparation
Ensure the installation site is properly excavated and prepared according to local regulations
and utility requirements.
Installation Steps
- Excavate area to required depth and dimensions
- Prepare stable base with compacted gravel
- Position valve box ensuring proper alignment
- Backfill with appropriate material in layers
- Compact each layer thoroughly
- Install cover and secure locking mechanism
Maintenance
Regular inspection and cleaning recommended. Check locking mechanism annually for proper
operation.
Common Applications
- Municipal Water Systems: Valve access for main water lines
- Industrial Plants: Process water control valves
- Commercial Properties: Irrigation system control points
- Fire Protection Systems: Fire hydrant control valves
- Utility Infrastructure: Gas and water distribution networks
